24"x 24" Roof Access Hatch - Steel Galv Model RAHGSS24X24
Free Delivery
US & Canada
*Additional handling charges may apply*
-
-
Best Seller: A superbly made hatch that is highly popular.
-
Easy Installation: The 24-inch size is the easiest to install.
-
Finish: Galvanized or Powder Coat.
-
Construction: Made with a 14-gauge galvanized steel cover, frame, and curb, featuring a 12-inch high curb and a 3 1/2 inch wide flange for secure attachment to the roof deck.
-
Cover: Includes a 14-gauge galvanized steel cover with a TPE rubber draft seal gasket door seal. The cover has a one-inch thick insulation liner, with an inside liner made of 22-gauge galvanized steel.
-
Curb: Constructed with a 14-gauge galvanized steel 12-inch high curb and a 3-1/2 inch wide flange.
-
Load/Deflection: Tested and approved to support a minimum live load of 40 lbs./ft² with a maximum deflection of 1/150th of the span, a maximum negative load of 50 lbs./ft² wind uplift, and a 110 mph wind load when the cover is in an open position.
-
Insulation: The curb includes one-inch fiberboard insulation surrounding the base and one-inch insulation between the exterior cover and liner.
-
Hardware: Includes corrosion-resistant heavy-duty hinge, slam latch, heavy-gauge automatic hold-open arm with red grip, compression spring-operated cylinders, exterior handle with integral padlock hasp, and interior locking handle with interior padlock hasp.
-
-
-
Lead time is 4-6 Weeks.
-
MOQ 5 Combined Hatch Sizes.
-
We Make to order; a Custom order is not returnable.
-
Stainless steel hardware kit available (includes outside components such as hinge, latch/lock hasp, and certain inside items).
-
-
- Phone 2899992334
- Email info@taimco.ca
- Contact us.
Roof access hatch with a 24-inch wide by 24-inch long opening, Constructed with a 14-gauge galvanized steel cover, frame, and self-flashing base.
This roof access hatch offers a 24-inch wide by 24-inch long opening and comes in a Galvanized or Powder coat colour. It is constructed with a 14-gauge galvanized steel cover, frame, and self-flashing base.
