TAIMCO Castle Heavy Duty Overhead Slide Gate (Manual Operation) solves particularly rigorous closure requirements. Truly a specialty gate, the Heavy Duty Overhead Slide Gate is made to withstand greater than normal stresses in huge openings. TAIMCO overhead gate systems have been installed in demanding applications throughout the US and Canada. Special features and design improvements, learned from years of experience in extreme high-use environments, reinforce the gate panel in critical areas. The installation method is versatile, as the gate may be hung between three pairs of 4” OD posts with a structural steel support beam or wall-mounted with the appropriate support system.

Key Features:

• • Durable Construction: Fabricated from 6063-T6 aluminum alloy extrusions. The primary members (top and bottom) are rectangular-shaped in cross-section with outside vertical members “P” shaped in cross-section.
  • Cross Bracing: Includes cross bracing of 3/16” minimum diameter stainless steel cable throughout the gate panel to keep the frame members square.
  • Special Bottom Guide Assemblies: Included for each side of the gate to ensure stability.
  • Self-Aligning Truck Assemblies: A minimum of two self-aligning, 4-wheeled, sealed, ball-bearing truck assemblies are supplied with each gate.
  • Versatile Installation: Can be hung between three pairs of 4” OD posts with a structural steel support beam or wall-mounted with the appropriate support system.

Specifications:

• • Material: 6063-T6 aluminum alloy extrusions.
  • Primary Members: Rectangular-shaped in cross-section with outside vertical members “P” shaped in cross-section.
  • Cross Bracing: 3/16” minimum diameter stainless steel cable.
  • Truck Assemblies: Self-aligning, 4-wheeled, sealed, ball-bearing truck assemblies.
  • Installation Method: Versatile installation options including hanging between posts or wall-mounted.
  • Download and Specification and details

Applications:

• • High-Traffic Areas: Ideal for securing high-traffic areas such as airports, border stations, and data centers.
  • Large Openings: Suitable for large openings requiring robust and reliable gate solutions.
  • Industrial and Commercial Sites: Perfect for industrial and commercial sites requiring durable and high-performance gates.
  • Public Service Buildings: Effective for securing public service buildings, public utilities, schools, and universities.
